一次性玉米淀粉餐具的整體結構設計介紹

一次性玉米淀粉餐具的整體結構設計介紹

網址:http://yphk.com.cn 手機頁面二維碼 2023-11-13 11:51:57

有廠家的一次性玉米淀粉餐具由餐具母體1和筷子盒2結合而成,即在餐具母體1上有一個長方形半圓筒狀凹腔3,在3的中部沿徑向有一條從底部開始的約1mm寬的狹縫4,該狹縫4距餐具母體的上表面約10mm止,筷子盒2由兩個特制水杯5和6對合而成,其中特制水杯5的杯口平面沿徑向有一個半圓形耳子7,其厚度約0.5mm,耳子7的中部有一直徑約3mm的小圓孔8,當裝配時,將筷子盒2嵌入餐具母體1上的半圓筒狀凹腔3時,該半圓形耳子7須從狹縫4穿出,然后再用塑料肖釘9貫入耳子7上的小圓孔8,并熔化固定,則筷子盒2和餐具母體1就緊密地連接為一個整體。

A manufacturer's disposable corn starch tableware is formed by combining tableware matrix 1 and chopstick box 2, which has a rectangular and semi cylindrical concave cavity 3 on tableware matrix 1. In the middle of the cavity 3, there is a radial slit 4 about 1mm wide starting from the bottom, which is about 10mm away from the upper surface of the tableware matrix. Chopstick box 2 is formed by pairing two special water cups 5 and 6, and the cup mouth plane of the special water cup 5 has a semicircular ear 7 along the radial direction, Its thickness is about 0.5mm, and there is a small circular hole 8 with a diameter of about 3mm in the middle of ear 7. When assembling, when inserting chopsticks box 2 into the semi cylindrical concave cavity 3 on tableware mother 1, the semi circular ear 7 must penetrate through the slit 4, and then use plastic nails 9 to penetrate into the small circular hole 8 on ear 7 and melt and fix it. Then, chopsticks box 2 and tableware mother 1 are tightly connected as a whole.
具體的在一次性玉米淀粉餐具母體1上,有一個寬約50mm,長約200mm的半圓筒形凹腔3,在3的中部約100mm處,從底部經外側面沿徑向開有一條約1mm寬的狹縫4,該狹縫4盤面約10mm止,特制水杯5,下部為圓錐形,上部為圓筒狀,寬度約10mm,在杯口平面沿徑向外沿處有一個半圓形耳子7,7上有一個直徑約3mm的小圓孔8:特制水杯6,下部為錐形,上部為圓筒形,寬度約10mm,圓筒直徑略小,可與特制水杯5的圓筒部分輕松套合,則5和6對合而成為一個中部帶有耳子7的簡形筷子盒2:當將2與1#合時,7從4穿出,再將肖釘9貫入小孔8,并熔化固定,則筷子盒2和餐具母體1就緊密地連接為一個整體——當就餐時,必須破壞性地將耳子7從筷子盒2上撕扯下來,則筷子盒2和餐具母體1才能完全分離,則水杯、筷子、匙子和牙簽等食具方可取出使用。正是基于這個破壞性的使用特征,就構成了一次性玉米淀粉餐具簡易、明確、且不可逆轉的判斷標識,確保它只能使用一次!
Specifically, on the disposable corn starch tableware matrix 1, there is a semi cylindrical concave cavity 3 with a width of about 50mm and a length of about 200mm. At the middle of the cavity 3, there is a slit 4 with a width of about 1mm from the bottom to the outer side radially. The slit 4 ends at about 10mm on the plate surface, and a special water cup 5 is made. The lower part is conical, and the upper part is cylindrical, with a width of about 10mm, There is a semicircular ear 7 on the outer edge of the cup mouth along the diameter. There is a small circular hole 8 with a diameter of about 3mm on the surface of the cup. The special water cup 6 has a conical lower part and a cylindrical upper part with a width of about 10mm. The cylindrical diameter is slightly smaller and can be easily fitted with the cylindrical part of the special water cup 5. Then, 5 and 6 are paired to form a simple chopsticks box with ears 7 in the middle. 2: When 2 is combined with 1 #, 7 passes through 4, and then the nail 9 is penetrated into the small hole 8, which is melted and fixed, Then chopsticks box 2 and tableware matrix 1 are tightly connected as a whole - when dining, the ears 7 must be destructively torn off chopsticks box 2, so that chopsticks box 2 and tableware matrix 1 can be completely separated, and utensils such as water cups, chopsticks, spoons, and toothpicks can only be taken out and used. It is precisely based on this destructive usage feature that constitutes a simple, clear, and irreversible identification for disposable corn starch tableware, ensuring that it can only be used once!
一次性環保餐具
玉米淀粉又稱玉米淀粉,俗稱六谷粉,是一種白色、淡黃色的粉末。
Corn starch, also known as corn starch, commonly known as six grain flour, is a white, light yellow powder.
玉米浸泡在0.3%的亞硫酸鹽中,經過粉碎、篩選、沉淀、干燥、研磨和其他工藝制成。
Corn is soaked in 0.3% sulfite and processed through crushing, screening, precipitation, drying, grinding, and other processes.
常見產品含有少量脂肪和蛋白質,吸濕性強,較高可達30%以上。玉米淀粉在許多方面都有重要的用途。
Common products contain a small amount of fat and protein, with strong moisture absorption, up to over 30%. Corn starch has important uses in many aspects.
餐具是一種可生物降解的產品,由玉米淀粉制成,并使用新的生產技術進行加工。它可以在自然條件下自我降解,避免環境污染,并節省石油等不可重復使用的資源。
Tableware is a biodegradable product made from corn starch and processed using new production technologies. It can self degrade under natural conditions, avoid environmental pollution, and save non reusable resources such as oil.
經相關檢測部門檢測,所有衛生和理化指標均符合相關標準,是餐飲市場廣泛使用的“餐具”的理想替代品。玉米淀粉基可生物降解餐具是一種無污染產品,在市場上受到提倡,并得到市場內政策的大力支持,以保障人們的生存和環境保護。
After testing by relevant testing departments, all hygiene and physicochemical indicators meet relevant standards, making it an ideal substitute for the widely used "disinfectant tableware" in the catering market. Corn starch based biodegradable tableware is a pollution-free product that has been advocated in the market and strongly supported by domestic policies to ensure people's survival and environmental protection.
